Caterpillar 996 Wheel Loader

Used Caterpillar 996 Wheel Loader

Used Equipment Condition Report: Clean and Tidy

Basic Information

Product Model: Used Caterpillar 996 Wheel Loader

Year of Production: 2023

Working Hours: 750 hours

Condition: Excellent, almost brand new



Previous Owner: Only one owner, used only for light-duty material handling

Application Areas: Mining, quarrying, port bulk material handling, earthmoving works, infrastructure construction, industrial site operations, water conservancy engineering

Maintenance Status

Maintenance: Regular maintenance, no fault records

Storage: Indoor storage, well maintained

Functionality: Fully functional, ready to use, maintenance-free





Get A Quote
Contact Us

Shares:

  • Description

Caterpillar 996 Wheel Loader – Technical Specifications

Item Specification
Model Caterpillar 996 / 996K / 996F Series
Engine Model Cat C27 ACERT (V12, turbocharged & aftercooled)
Gross Power 521 kW 873 hp @ 1800 rpm
Net Power 507 kW 860 hp @ 1800 rpm
Displacement 27.0 L 1648 cu.in.
Operating Weight Approx. 92,700 kg 204,360 lb
Bucket Capacity Range 9.2 – 18.0 m³ 12.0 – 23.5 cu.yd
Standard Bucket 12.0 – 14.0 m³
Breakout Force 485 kN
Lift Capacity (Full Turn) ≥ 22,000 kg
Hydraulic System Pressure 31.4 MPa 4550 psi
Hydraulic Pump Flow 640 L/min
Fuel Tank Capacity 1250 L
Hydraulic Oil Capacity 295 L
Transmission Cat planetary power shift, 4F / 2R
Max Travel Speed 34.5 km/h
Length (standard bucket) 12.8 m
Width over tires 3.5 m
Height to top of cab 4.8 m
Turning Radius 7.9 m
Emission Standard EPA Tier 4 Final / EU Stage IV



Caterpillar 996 Wheel Loader– Product Description

Description

The Cat 996 Wheel Loader is a heavy-duty, large-scale wheel loader designed for high-volume material handling, mining, quarrying, and heavy construction operations. It delivers exceptional power, durability, and productivity for the most demanding workloads.


Key Features

  • Equipped with a high-power, low-fuel-consumption Cat diesel engine that provides strong torque and reliable performance, meeting international mainstream emission standards.
  • Load-sensing hydraulic system ensures smooth and precise control, with fast cycle times and high composite action efficiency.
  • Articulated frame design for a small turning radius and flexible maneuvering on various job sites.
  • Ergonomic, low-noise cab with wide visibility and comfortable operating environment to reduce driver fatigue.
  • High-strength structural frame and wear-resistant components for long service life, high durability and low maintenance cost.
  • Stable performance under heavy loads, suitable for long-hour continuous operation in mining, quarry and earthmoving conditions.

Applications

Suitable for large-scale mining, quarry operations, bulk material handling, port loading, earthmoving projects, infrastructure construction and heavy-duty earthworks.
