| Specification |
Detail |
| Model |
SANY SY26U |
| Engine Manufacturer |
Yanmar |
| Engine Model |
4TNV98C |
| Engine Power |
18.4 kW (24.5 HP) |
| Operating Weight |
2,600 kg |
| Bucket Capacity |
0.08 m³ |
| Max Digging Depth |
2,395 mm |
| Max Reach at Ground |
4,310 mm |
| Max Dumping Height |
3,120 mm |
| Swing Speed |
9.4 rpm |
| Max Travel Speed |
8.2 km/h (high) / 4.4 km/h (low) |
| Hydraulic System |
Load Sensing System |
| Operating Pressure |
23.5 MPa |
| Track Width |
1,560 mm |
| Overall Length |
5,350 mm |
| Overall Width |
1,960 mm |
| Overall Height |
2,480 mm |
| Fuel Tank Capacity |
55 L |
| Hydraulic Tank Capacity |
30 L |
| Cooling System |
Water-cooled |
| Undercarriage Type |
Rubber Tracks |
| Cabin Type |
Open cabin with safety glass |
| Operating Temperature |
-20°C to +45°C |
This table provides an overview of the key technical specifications for the SANY SY26U Used Excavator. With its compact design and robust performance, this machine is ideal for various small to medium-scale construction tasks. It combines the reliability of a Yanmar engine with a load-sensing hydraulic system for improved productivity and fuel efficiency.
